Tech specs |
Classification
|
Electro-optical combined radio channel security detector
|
Type of detector |
Wireless
|
Installation method
|
Indoors
|
Compatibility
|
Operates with all Ajax hubs, range extenders, ocBridge Plus, uartBridge
|
Sensing element
|
PIR sensor, electret microphone
|
Alarm signal delivery time
|
0.15 s
|
Motion detection distance
|
Up to 12 m
|
Detection angles
|
Horizontal — 88.5° Vertical — 80°
|
Time for motion detection
|
From 0.3 to 2 m/s
|
Recommended installation height
|
2.4 m
|
Pet immunity
|
Weight — up to 20 kg Height — up to 50 cm
|
Break detection distance
|
Up to 9 m
|
Detection angle
|
180°
|
Sensitivity
|
Adjustable, 3 levels
|
Power supply
|
Battery: CR123A battery, 3 V
|
Battery life
| Up to 5 years |
Jeweller radio technology
|
Communication range with central unit — up to 1,200 m in an open space Two-way communication between devices
Radio frequency bands: 921.0 – 922.0 MHz (depends on the region of sale)
Self-adjusting RF output power — up to 20 mW Block encryption based on AES algorithm Detector polling period — 12−300 s
|
Temperature sensor
|
Available
|
Operating temperature range
|
From -10°С to +40°С
|
Permissible humidity
|
Up to 75%
|
Anti-sabotage |
Protection against fraud Jamming detection Tamper-resistant
|
Remote setting and testing
| + |
Dimensions |
110 × 65 × 50 mm
|
Weight |
92 g
|
Warranty |
Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
|
Complete set
|
CombiProtect combined motion and glass break detector SmartBracket mounting panel CR123A battery (pre-installed) Installation set User's guide
|
