Tech specs
|
Installation method
| Indoors
Outdoors
in sealed box or inside the detector casing
|
Compatible control panels
| All Ajax hubs |
Compatible range extenders
| All Ajax range extenders |
Compatible wired devices |
All Ajax detector or device with NC/NO contact type
|
Alarm input
| 1 |
Supported normal state of alarm input
| Normally closed (NC)
Normally open (NO) |
Supported third-party device type
| Pulse
Bistable |
Tamper input
| 1 |
Supported normal state of tamper input
|
Normally closed (NC)
Normally open (NO)
|
Power supply output for the wired detector or device
| 3.3 V⎓ |
Adjustable alarm types
|
Intrusion
Fire
Medical help
Panic button
Gas alarm
Malfunction
Leakage
Custom
If the Custom type of the event is selected, notifications about it will not be sent to the security company's control panel and via SMS to system users.
|
Module power supply
| 3 × CR123A battery
pre-installed |
Battery life
|
Up to 5 years
|
Jeweller radio technology
|
Communication range with hub or range extender
up to 1,600 m
in an open space
Two-way communication between devices
Radio frequency bands:
921.0 – 922.0 MHz
depends on the sales region
Maximum effective radiated power (ERP)
up to 20 mW
Block encryption with a dynamic key
Device polling interval
12−300 s
|
Temperature sensor
|
Available
The temperature is displayed in the device states in the Ajax apps.
|
Operating temperature range
| –25°С to +50°С |
Operating humidity
|
Up to 75%
|
Anti-sabotage |
Protection against spoofing |
| Jamming detection
Accelerometer
Tamper terminals
|
Remote setting and testing
| + |
Dimensions
| 100 × 39 × 22 mm |
Weight
|
74 g
|
Warranty
|
24 months
|
Complete set |
Transmitter |
| 3 × CR123A battery (pre-installed)
Installation set
Quick Start Guide
|
