Tech specs
|
Classification
| Radio channel relay unit
|
Device type
|
Wireless
|
Installation method
|
Into electric switchboard, junction box
|
Compatibility
|
Operates with all Ajax hubs and range extenders
|
Actuating element
|
Electromagnetic relay
|
Relay service life
| 200,000 switch-ons |
Voltage protection
|
Max — 36.5 V⎓, min — 6.5 V⎓
|
Maximum load current
|
5A at 24 V⎓, 13A at 230V~
|
Maximum current protection
| No |
Maximum temperature protection
|
> 65°C at the place of installation
|
Electric power meter function
| No |
Energy consumption parameter check
|
Voltage
|
Power supply
|
7–24 V⎓ (DC only)
|
Operation modes
| Pulse Bistable |
Contact state
| Normally open Normally closed |
Adjustable pulse duration
| 1–255 sec |
Jeweller radio technology |
Communication range with central unit — up to 1,000 m in |
| an open space Two-way communication between devices
Radio frequency bands: 921.0 – 922.0 MHz (depends on the region of sale)
Self-adjusting RF output power — up to 20 mW Block encryption based on AES algorithm Device scanning period — 12–300 s
|
Operating temperature range |
From –20°С to +64°С
|
Permissible humidity
|
Up to 85%
|
Protection class of body
|
IP20
|
Anti-sabotage
| Protection against fraud Jamming detection |
Remote setting and testing
| + |
Dimensions
|
39 × 33 × 18 mm
|
Weight
|
25 g
|
Warranty
|
Replacement and repair within 24 months of the date of sale.
|
Complete set
|
Relay Installation kit Quick Start Guide
|
|
